AWI Economy vs Custom vs Premium Grades: What Each Requires of Your Drawings

AWI Economy vs Custom vs Premium Grades: What Each Requires of Your Drawings
Quick answer

AWI aesthetic grades set the degree of control over exposed woodwork. Economy is the minimum, Custom is the default when a spec names no grade, and Premium is the highest, with tighter gap and alignment tolerances and stricter grain and veneer matching. Grade does not set strength; casework duty level does. Shop drawings must state the grade and show the matching, scribes and materials it requires.

Key facts
The three grades
Economy, Custom and Premium, defined by degree of control
Default grade
Custom, when the spec cites the standard but names no grade
Viewing distance
Inconspicuous at 24 in. Premium, 48 in. Custom, 72 in. Economy

The grade an architect specifies is more than a quality target for the finished woodwork. It sets measurable tolerances, matching rules and material minimums, and the shop drawings are the first place a reviewer checks whether the shop understood them. This guide explains what Economy, Custom and Premium mean in the current AWI standards and what each one changes on the sheet.

What a grade controls

AWI's standards define three aesthetic grades by the degree of control over materials, workmanship and manufacture. Economy is the minimum degree of control, Custom is a high degree and Premium is the highest. In ANSI/AWI 0641, Architectural Wood Casework, aesthetic performance is an evaluation of the surfaces that will be exposed or semi-exposed after installation.

Two points are often missed:

  • Grade is not structural. Older AWI standards bundled appearance and construction into a single grade. ANSI/AWI 0641 splits them. Aesthetic grade covers how casework looks, and a separate Duty Level, 1 through 4, covers tested structural performance. A Premium cabinet is not automatically a stronger cabinet, and an Economy storeroom cabinet may still carry a high duty level.
  • Grade applies to what is seen. Under 0641, concealed surface materials are at the manufacturer's option, and semi-exposed surfaces have to match exposed surfaces only if the spec says so.

A useful measure of the difference is the viewing distance the standard attaches to the word inconspicuous: not readily visible without careful inspection at 24 in. for Premium, 48 in. for Custom and 72 in. for Economy.

Where the grade comes from

The grade is set in the specification, usually in the Division 06 section for the item: 06 41 00 Architectural Wood Casework and its subsections, 06 42 00 for wood paneling, and 06 20 00 or 06 40 00 for finish carpentry and general architectural woodwork. Look for three things:

  • The standard and edition behind the grade. The Architectural Woodwork Standards, Edition 2 (2014) and the current ANSI/AWI standards both use the names Economy, Custom and Premium, but the clauses behind the names are not identical.
  • Whether the grade varies by area. Specifications can assign Premium to feature spaces and Custom to the balance of the job, or call out individual items.
  • Project-specific overrides. A spec can name Custom Grade and still require a particular veneer match, edge or construction that goes beyond it.

If the spec references ANSI/AWI 0641 and names no grade, the standard defaults to Custom Grade and Duty Level 3. The installation standard, ANSI/AWI 0620, and the paneling standard, ANSI/AWI 0642, also default to Custom. Confirm in writing anyway. A default tells you what the standard assumes, not what the architect intended.

Economy grade

Economy is the minimum level of control. It suits storage rooms, utility areas and back-of-house work where appearance is secondary. In ANSI/AWI 0641, Economy leaves to the manufacturer several choices that the higher grades fix:

  • Grain or pattern on drawer fronts may run vertically or horizontally at the manufacturer's option for the whole project, doors run vertically, and mismatch is permitted.
  • Fastener cover caps on exposed interior surfaces are not required.
  • The scribe filler limits that apply at Custom and Premium do not apply.
  • Cabinet backs are required only where the back is an exposed surface.

Economy does not mean no standard. Edgebanding is still required, doors are still edgebanded on all four edges, and gap and alignment tolerances still apply at wider values. The drawings still need the full AWI 100 content: cover sheet, plans, elevations, sections, joinery and attachment.

Custom grade

Custom is the default grade in the AWI standards and the one to expect on typical commercial interiors unless the spec says otherwise. Under ANSI/AWI 0641 it requires, among other things:

  • Grain or pattern on doors, drawer fronts and false fronts that runs and matches vertically within each cabinet, with fronts compatible in color across multiple faces in each room.
  • Fastener cover caps, in a color compatible with the interior finish, at exposed interior surfaces.
  • Scribe fillers or scribe moulding permitted, with a maximum installed filler width of 3 in.
  • For transparent finish, exposed exterior veneer of at least HPVA Grade A, with solid stock and veneer compatible in color and grain.
  • Visible core at laminate drawer box joinery edgebanded, painted or stained to match the drawer side.

On the drawings, that translates into grain direction shown on elevations, edge treatments and scribes shown in section, and laminate or veneer selections called out room by room so compatibility can be checked.

Premium grade

Premium is the highest degree of control and is typically reserved for feature areas. Under ANSI/AWI 0641:

  • Grain on doors, drawer fronts and false fronts runs and matches vertically and is sequenced horizontally within each cabinet, and fronts are well matched for color and grain across multiple cabinet faces in one elevation.
  • Cathedral grain runs crown up, in the same direction for the entire project.
  • Exposed exterior veneer for transparent finish is at least HPVA Grade AA, and adjacent veneer panels are well matched for color and grain.
  • Exposed interior surfaces for transparent finish are the same species and cut as the exposed exterior.
  • Scribe moulding is not permitted, and scribe fillers are limited to a 2 in. installed width.
  • Exposed ends are of integral construction, not secondarily applied.

For wall paneling under ANSI/AWI 0642, Premium veneer is book-matched and balanced within each panel face, where Custom requires book-matched only.

It is just as important to know what Premium does not include automatically. In 0641, blueprint matching or sequencing between cabinets is required only if specified. In 0642, made-to-order, end-matched and blueprint-matched panel sets are required only if specified. If the architect's elevations imply a continuous matched wall and the spec does not say how it is to be achieved, raise it before drafting. Premium sets carry the most information of any grade, so allow for it when scoping the drafting. The complete guide to commercial millwork shop drawings covers how a full set is organized.

Tolerances side by side

Selected values from the current online editions, listed as Premium / Custom / Economy. Verify them against the edition your project cites before using them as acceptance criteria.

  • Inconspicuous viewing distance: 24 in. / 48 in. / 72 in.
  • Edge alignment of doors and drawer fronts (0641): 0.031 in. / 0.047 in. / 0.063 in.
  • Doors and drawer fronts in the same flat plane (0641): 0.031 in. / 0.063 in. / 0.125 in.
  • Installed gaps at wood-to-wood field joints (0620): 0.016 in. / 0.031 in. / 0.047 in.
  • Installed flushness at flat wood-to-wood field joints (0620): 0.016 in. / 0.031 in. / 0.047 in.
  • Maximum installed scribe filler width: 2 in. / 3 in. / no requirement.

These numbers matter to the drafter because they decide what is buildable. A reveal pattern that depends on every door landing within a few hundredths of an inch needs hardware with enough adjustment and a scribe strategy that absorbs wall conditions inside the allowed filler width. Those decisions belong on the drawings, not on site.

How to draw to the specified grade

  1. Pull the grade, duty level, standard and edition from the project manual. AWI 100 requires the specified grade on the cover sheet and the aesthetic grade and duty level indicated on the drawing set.
  2. Map grades to areas. On a mixed-grade job, tag each elevation or room with its grade so a single cover note is not left to cover everything.
  3. Put grain and matching on the elevations. Show grain direction, and for transparent finish give veneer species, cut, leaf match, panel match and room match.
  4. Detail scribes, fillers and exposed ends to the grade's limits.
  5. Complete the material list. Exposed, semi-exposed and concealed surface materials, core, edgebanding and hardware.
  6. Check library details against the grade. A typical section built for Custom can quietly break a Premium requirement.
  7. Write an RFI for every gap between what the grade requires and what the documents show. Our guide to writing a millwork RFI covers the format.

One point that saves argument: under AWI 100, sample requirements are the same regardless of the grade specified. A lower grade does not shrink the sample submittal.

Millmetric drafts to the grade and edition your specification cites, in Microvellum, Cabinet Vision, AutoCAD and BricsCAD, and every set gets a senior review before delivery. If you have a mixed-grade package to scope, send the drawings for a fixed-price estimate within 24 to 48 business hours.

Common grade mistakes

  • Treating Premium as better materials everywhere. Grade governs exposed and semi-exposed surfaces. Concealed materials remain the manufacturer's choice unless specified.
  • Assuming grade sets strength. Structural performance is the duty level. State both.
  • One grade note for a mixed-grade job.
  • Adding matching the spec did not ask for, or missing matching it did. Sequencing between cabinets and blueprint-matched panels are specification items, and they change veneer purchasing.
  • Mixing fabrication and installed tolerances. ANSI/AWI 0641 refers final adjustment of gaps, flushness and alignment to the installation standard, ANSI/AWI 0620.
  • Citing clause numbers from the wrong edition. A reference to AWS Edition 2 on a job specified to the ANSI/AWI standards invites a comment.

For how grade fits into the wider question of what a compliant set contains, see what AWI compliance means for your drawings. For the review-stage errors that follow from getting it wrong, see the five submittal mistakes that get packages kicked back.

Frequently asked questions

What is the difference between AWI Custom and Premium grade?

Both control exposed and semi-exposed woodwork, but Premium is tighter. Under ANSI/AWI 0641, Premium requires grain sequenced horizontally within each cabinet and well matched across an elevation, higher minimum veneer grade, no scribe moulding and narrower scribe fillers. Alignment tolerances are also smaller, and defects must be inconspicuous at 24 inches instead of 48.

Which AWI grade applies if the specification does not name one?

Custom. ANSI/AWI 0641 states that when the standard is referenced in the contract documents and no aesthetic grade is specified, casework must meet Custom Grade, with Duty Level 3 as the default for structural performance. The installation and wood paneling standards also default to Custom. Confirm by RFI where the documents are unclear.

Does a higher AWI grade mean stronger cabinets?

No. In ANSI/AWI 0641, aesthetic grade covers appearance, while structural performance is expressed separately as Duty Level 1 through 4, with typical applications from light commercial to laboratory. A cabinet's duty level is the lowest tested value among its joinery, materials and components. Shop drawings should state both the grade and the duty level.

Do AWI grades change what a shop drawing set must include?

The required drawing content in AWI 100 Submittals is the same for every grade: cover sheet, plans, elevations, sections, joinery, attachment and material lists. What changes is the detail those drawings must prove, such as grain direction and veneer matching, scribe type and width, edge treatments and interior surface materials. Sample requirements are also the same regardless of grade.
